Triumph Tiger 800 XCA [2017-2020] - Gear Lever

Adjustable Gear Lever for the Triumph Tiger 800 XCA

The CNC-milled gear lever from SW-MOTECH is made of a high-quality aluminum alloy and can be continuously adjusted for an ergonomic shift position.

Advantages

• Two-piece construction with continuously adjustable unit
• Improved ergonomics and safe operation
• Folding mechanism with spring for protection in falls
• Toe peg can be installed rotated by 180 degrees
• Prepared for an optional gear lever extension

Technical Details

• Adjustment range between toe peg and shift shaft: 132 to 187 mm
• Original distance between toe peg and shift shaft: 160 mm
• Material: Aluminum
• Surface: anodized and HART-COAT® coated
• Color: Black and Silver
• Total weight: approx. 0.2 kg

Scope of Delivery and Notes

• 1 gear lever
• Fitting instructions
• Mounting material
• No ABE required for road use in Germany
• Folding away when tipping over is only guaranteed when the lever is mounted in the standard position facing forward.
